- Size: 9
- Place of Origin: China
- Brand Name: JIAOYANG
- Model Number: GWC-2500D
- Weight: 45000.000 kg
1.The main technical parameters of manufacturing machine
BRC MESH MACHINE,WIRE MESH WELDING MACHINE,WELDED MESH MACHINE,WIRE STRAIGHTENING AND CUTTING MACHINE,BRICK FORCE MESH MACHINE, WELDED MESH MACHINE, AUTOMATIC FENCE MESH WELDING MACHINE, ANIMAL CAGES WELDING MACHINE, MINE TIMBERING MESH WELDING MACHINE AND SO ON.
Wire dimater | 3-5mm | Line wire feed | from the coil |
Cross wire space | 50-200mm | Cross wire feed | precut |
Line wire space | 50-200mm | Rated voltage | 380V |
Width of mesh | 2500mm | Rated electrical power | 6*125KVA |
Welding speed | 60times/min | max number of electrodes | 48 |
| Machine weight | 4.5t | overall dimension | 2200*2600*1800mm |
2.Application of manufacturing machine
1.mesh fence,casting roof mesh in the building
2.Construction ( 3d panel covered mesh, floor warmness preserving mesh, seedbed mesh, floor room mesh,animal cages
1. PLC program (Panasonnic)&touch screen (Delta)
2. Servo motor (Panasonnic) for pulling mesh, can adjust cross wire space online.
3. Servo motor (Panasonnic) for feeding cross wires, automatically from wire coil.
4. The main motor, for the upper welding electrodes, will use inverter (inverter).
5. Equip with automatic mesh cutting machine.
6. The error of angle line is +/-5mm. The error of horizontal is +/-3mm.
Packaging & Shipping--- Hebei jiaoyang wire mesh machine co.,ltd,
1. The main multi spot welding machine is packed by plastic.
2. The spare parts and the electric cabinet are packed by wooden box.
1 Our technician will help you install the wire mesh machine and training your workers. Main machine warranty is one year.
2 If have problem contact us at any time . We promise to do our best to help you.
Note: we can also customize the machines based on our clients special requirements .
